What Is The Towing Capacity Of A 2025 Toyota Sequoia?
Toyota Sequoia Towing Capacity Overview
- Maximum towing capacity of up to 9,520 pounds and a top payload of 1,730 pounds when properly equipped.
- Motived by the i-FORCE MAX Twin-Turbo V-6 Hybrid engine, delivering 437 horsepower and 583 lb-ft of torque.
- Standard towing equipment includes a Class-IV towing hitch receiver and seven-pin/four-pin connector wiring harness, plus TOW/HAUL drive modes and Trailer-Sway Control.
- Available towing features include Load-leveling Rear Height Control Air Suspension and a Trailer Backup Guide system with Straight Path Assist.
2025 Toyota Sequoia Towing Capacity
Along with a spacious, full-size body that seamlessly blends rugged power with modern amenities, the Toyota Sequoia towing capacity makes for a versatile vehicle for drivers seeking a well-appointed model that's ready to take on any adventure. The team from DARCARS 355 Toyota of Rockville gives you an in-depth look at how this luxury-inspired three-row SUV achieves a max towing capacity of nearly 10,000 pounds.1
Built from lightweight, high-strength materials and hailed as a true towing titan, the 2025 Toyota Sequoia SUV features a hybrid powertrain that seamlessly blends gas and electric power to deliver an impressive maximum towing capacity of up to 9,520 pounds1 and a maximum payload rating of 1,730 pounds2.
That being said, the Toyota Sequoia towing capacity varies across its lineup of six trim levels, each delivering its own rating based on its purpose and configuration. For example, the 2025 Toyota Sequoia TRD Pro – engineered for conquering rugged terrain – offers a maximum towing capacity of 9,020 pounds.1 Meanwhile, the top-tier Capstone trim, known for its elevated refinement and dark American walnut wood-grain interior accents, delivers a maximum tow rating of 8,980 pounds.1
Explore the Toyota Sequoia towing specs for each variant, including max payload capacity, below:
| 2025 Toyota Sequoia Towing Capacity Chart | |||||
|---|---|---|---|---|---|
| Trim Level | Engine | Transmission | Max Towing Capacity | Max Payload Capacity | Base Curb Weight |
| SR5 | i-FORCE MAX 3.445L V-6 Hybrid | 10-speed automatic |
|
|
|
| Limited | i-FORCE MAX 3.445L V-6 Hybrid | 10-speed automatic |
|
|
|
| Platinum | i-FORCE MAX 3.445L V-6 Hybrid | 10-speed automatic | 9,010 lbs (4WD)1 | 1,410 lbs (4WD)2 | 6,150 lbs (4WD) |
| 1794 Edition | i-FORCE MAX 3.445L V-6 Hybrid | 10-speed automatic | 9,010 lbs (4WD)1 | 1,410 lbs (4WD)2 | 6,150 lbs (4WD) |
| TRD Pro | i-FORCE MAX 3.445L V-6 Hybrid | 10-speed automatic | 9,020 lbs (4WD)1 | 1,435 lbs (4WD)2 | 6,150 lbs (4WD) |
| Capstone | i-FORCE MAX 3.445L V-6 Hybrid | 10-speed automatic | 8,980 lbs (4WD)1 | 1,375 lbs (4WD)2 | 6,185 lbs (4WD) |
As we look at the chart, the Sequoia SR5 2WD SUV is going to be the choice for drivers wanting to reach the maximum towing rating of 9,520 pounds.1 This configuration will also ensure you hit the max payload capability of 1,730 pounds.2
Curious how these numbers compare to other trucks or SUVs in the lineup? Check out more Toyota model research online to see how the Sequoia stacks up against other Toyota vehicles like the Tundra, Highlander, or 4Runner.
Toyota Sequoia Towing Package & Performance Features
The new Toyota Sequoia equips you with everything you need to make towing safer and more convenient. Every Sequoia full-size SUV comes standard with a Class-IV towing hitch receiver and a wiring harness featuring seven-pin and four-pin connectors. Towing technologies include standard TOW/HAUL drive modes, an Integrated Trailer Brake Controller, and Trailer-Sway Control.
The 2025 Toyota Sequoia offers an available Tow Technology Package on the SR5 trim, featuring a digital rearview mirror and Trailer Backup Guide system. A modified version of this package – available on all other iterations except the Capstone – adds a wireless trailer camera and an additional exterior antenna. The Capstone Grade Package includes all the equipment listed here, plus powered tow mirrors.
In addition, the Sequoia enhances ride quality and towing confidence with its available Adaptive Variable Suspension, which continuously adjusts damping for changing road conditions. This feature helps maintain optimal height, reduce body roll, and deliver a smooth, stable drive.
Toyota Sequoia Towing Capacity By Year
With the latest Toyota Sequoia offering a towing capacity of up to 9,520 pounds,1 how does this new SUV stack up against its predecessors? Explore the towing weight for Toyota Sequoia models from previous years to see the evolution.
| Toyota Sequoia Towing Capacity By Year | |||
|---|---|---|---|
| Year | Engine | Max Towing Capacity | Max Payload Capacity |
| 2025 Toyota Sequoia | i-FORCE MAX 3.445L V-6 Hybrid | 9,520 lbs1 | 1,730 lbs2 |
| 2024 Toyota Sequoia | i-FORCE MAX 3.445L V-6 Hybrid | 9,520 lbs1 | 1,730 lbs2 |
| 2023 Toyota Sequoia | i-FORCE MAX 3.445L V-6 Hybrid | 9,520 lbs1 | 1,730 lbs2 |
| 2022 Toyota Sequoia | 5.7L V-8 | 7,400 lbs1 | 1,370 lbs2 |
| 2021 Toyota Sequoia | 5.7L V-8 | 7,400 lbs1 | 1,370 lbs2 |
| 2020 Toyota Sequoia | 5.7L V-8 | 7,400 lbs1 | 1,370 lbs2 |
Whether you're interested in the brand-new 2025 Sequoia or are on the hunt for a slightly older V-8 version, reach out to our team to learn how to finance a Toyota Sequoia, new or pre-owned.
Test Drive and Experience a 2025 Toyota Sequoia SUV Today!
The 2025 Toyota Sequoia truly stands out as a remarkable SUV, seamlessly blending powerful capability with elevated luxury across all three rows. Explore the full range of trim levels in our all-new Toyota inventory and find the perfect combination of features and Toyota Sequoia towing capacity to suit your lifestyle.
Frequently Asked Questions
What towing packages are available for the Toyota Sequoia?
The Toyota Sequoia offers the available Tow Technology Package that includes a digital display rearview mirror, an exterior antenna, a wireless trailer camera, and a Trailer Backup Guide with a Multi-Information Display screen. This package is optional on all trims except for the SR5 (which has a modified version of this package) and the Capstone, which can be outfitted with the comparable Capstone Grade Package.
Can a Sequoia tow 10,000 pounds?
The 2025 Toyota Sequoia comes slightly below a 10,000-pound tow rating,1 with the ability to haul up to 9,520 pounds when properly equipped. This capability gives you plenty of power to tow a number of items, including small to midsize trailers, teardrop campers, pop-campers, and select toy haulers. Recreational vehicles include ATVs, motorcycles, Jet Skis, and more.
How much can a V-8 Toyota Sequoia tow?
While the latest Toyota Sequoia no longer features the V-8 engine found in the 2022 model, a used Sequoia equipped with this discontinued powertrain can still tow up to 7,400 pounds when properly equipped. Introduced for the 2023 model year, the i-FORCE MAX Twin-Turbo Hybrid V-6 powertrain significantly enhanced the SUV's towing capabilities, offering a notable upgrade in performance and efficiency.
